Ensy InoVent AHU 200 right and left variants are built for wall mounting and are well suited for apartments and small single-family homes. The models are based on the best available technology, resulting in energy efficiency and low noise levels. Very user-friendly control.
Ventilation unit
InoVent AHU 200 H and V
InoVent
Previous generation
TECHNICAL DATA AHU-200 H and V
| Heating coil | -phase/voltage | (50Hz/VAC) | ~1 / 230 |
| -power consumption | (W) | 800 | |
| Fans | -phase/voltage | (50Hz/VAC) | ~1 / 230 |
| -Total current draw both fans at NORM operation | (A) | 0,19 | |
| Fuse size | (A) | 10 | |
| Automation system | Integrated | ||
| Filter class | Superpleat | F7 | |
| Thermal insulation | Sides and top/bottom | 25 mm | |
| Front door | 50 mm | ||
| Weight | (kg) | 47 | |
| Airflow (Supply) | [m³/h] | ||
| Pressure (Supply) | [PA] | ||
AHU-200 H AHU-200 V
| |||
| Airflow (Extract) | [m³/h] | ||
| Pressure (Extract) | [PA] | ||
| AHU-200 H AHU-200 V
| |||
Dokumentnavn |
Modell |
Språk |
 |
392129-2 WIRING DIAGRAM. AHU-200-700. InoVent (rev2.1) | Høyre/Venstre | Norsk |
|
393933-2 Bruker og installasjonsmanual InoVent AHU-200-700_NO_Rev 1.8. Desember 22 | Høyre/Venstre | Norsk/English |
|
Modbus manual LMC311 Air Handling Unit Controller_UK v 2.0 | Høyre/Venstre | English |
|
Dokumentasjon InoVent AHU 200 H og V | Høyre/Venstre | English |
