Ensy Wave AHU 700 right and left variants are built for wall mounting and are well suited for larger apartments and single-family homes. The models are based on the best available technology, resulting in energy efficiency and low noise levels. Very user-friendly controls
Ventilation unit
Wave AHU 700 BH and BV
Wave
Current series
TECHNICAL DATA AHU-700 BH and BV
| Heating coil | -phase/voltage | (50Hz/VAC) | ~1 / 230 |
| -power consumption | (W) | 1200 | |
| Fans | -phase/voltage | (50Hz/VAC) | ~1 / 230 |
| -Total current draw both fans at NORM operation | (A) | 0,83 | |
| -speed at MAX operation | o/min | 2100 | |
| Fuse size | (A) | 10 | |
| Automation system | Integrated | ||
| Filter class | Superpleat | F7 | |
| Thermal insulation | (mm) | 40 | |
| Weight | (kg) | 101 | |
| Airflow (Supply) | [m³/h] | ||
| Pressure (Supply) | [PA] | ||
AHU-700 BH AHU-700 BV
| |||
| Airflow (Extract) | [m³/h] | ||
| Pressure (Extract) | [PA] | ||
| AHU-700 BH AHU-700 BV
| |||
Dokumentnavn |
Modell |
Språk |
 |
392129-2 WIRING DIAGRAM AHU-200-700 | Høyre/Venstre | English |
|
393933-2 Bruker og installasjonsmanual AHU-200-700 | Høyre/Venstre | English |
|
Modbus manual LMC311 Air Handling Unit Controller_UK v 2.0 | Høyre/Venstre | English |
