Ensy Wave AHU 300 right and left variants are built for wall mounting and are well suited for apartments and small single-family homes. The models are based on the best available technology, resulting in energy efficiency and low noise levels. Very user-friendly control.
Ventilation unit
Wave AHU 300 BH and BV
Wave
Current series
TECHNICAL DATA AHU-300 BH and BV
| Varmebatteri | -fase/spenning | (50Hz/VAC) | ~1 / 230 |
| -effekt forbruk | (W) | 800 | |
| Vifter | -fase/spenning | (50Hz/VAC) | ~1 / 230 |
| – Totalt strømtrekk begge vifter ved NORM drift | (A) | 0,27 | |
| -turtall ved MAX drift | o/min | 2100 | |
| Sikringsstørrelse | (A) | 10 | |
| Automatikksystem | Integrert | ||
| Filterklasse | Superpleat | F7 | |
| Termisk isolasjon | (mm) | 40 | |
| Vekt | (kg) | 54 | |
| Airflow (Supply) | [m³/h] | ||
| Pressure (Supply) | [PA] | ||
AHU-300 BH AHU-300 BV
| |||
| Airflow (Extract) | [m³/h] | ||
| Pressure (Extract) | [PA] | ||
| AHU-300 BH AHU-300 BV
| |||
Document name |
Model |
Language |
 |
WIRING DIAGRAM AHU-200-700 | Right/Left | English |
|
393933-2 User and installation manual AHU-200-700 | Right/Left | English |
|
Modbus manual LMC311 Air Handling Unit Controller_UK v 2.0 | Right/Left | English |
